AGR021

AGR021

STASTO Combination
fully assembled and tested
distributor 4-fold both sides;
inlet 1/2";
outlets ball valve 3830-1/4"; 8mm "Push-In"-connection

Intrastat No.: 84818081
Country of origin: Italy
Weight: 1.493 Kg
Short Itemnumber: AGR021
https://www.stasto.si/web/image/product.template/224094/image_1920?unique=ba7a68c

STASTO Combination
fully assembled and tested
distributor 4-fold both sides;
inlet 1/2";
outlets ball valve 3830-1/4"; 8mm "Push-In"-connection

231,30 € 231.3 EUR 231,30 €

cena na zahtevo

excl. tax
  • Connection
  • Dimension
  • Function
  • Max. inlet pressure
  • Flow at 6bar/Δp=1bar
  • Filter element
  • Brand

This combination does not exist.

Availability:
See availability
Contact Us

Technical specifications

Brand STASTO
Brand STASTO
Distributor DI03-12-8-14
DI03-12-8-14 x 1.0 Pcs
Distributor DI03-12-8-14
Distributor Series DI03; Material Anodized aluminum; Outlet thread 1/4"; Connecting thread 1/2"; Outlets Double-sided; Distance of outlets 36mm; Number of outlets 8
Ball valve made of brass 3830-1/4"
3830-1/4" x 8.0 Pcs
Ball valve made of brass 3830-1/4"
Ball valve made of brass Series 3830; Mini type; Female thread; Seals PTFE/NBR; Medium temperature -20...+90°C; Turning handle Polyamide; Pressure range 0...10bar; G 1/4"; Nominal diameter 8mm; Length 41mm
Plug screw TH50-12-N-0
TH50-12-N-0 x 1.0 Pcs
Plug screw TH50-12-N-0
Plug screw Series TH50; Nickel plated brass; With o-ring NBR; Cylindrical thread; Hexagon socket; Thread 1/2"
