BA116-65-S2-A

Name: BA116-65-S2-A
Brand: STASTO
SKU: BA116-65-S2-A
Price: 2690.1 EUR
Availability: InStock

Flanged ball valve with pneumatic actuator; ATEX II 2 G/D c T3; Flange PN63; Body Steel; Ball 1.4301; Ball seal fibre-glass-reinforced PTFE; Stem seal graphite/PTFE/FKM; Single acting actuator ATEX II 2 G/D c T6; Control pressure 4...8bar; Medium temperature -20...+160°C; Pressure range 0...40bar; Nominal diameter 65mm; Length 125mm; Actuator PAS1604

Intrastat No.: 84818081
Country of origin: Italy
Weight: 56.29 Kg
Short Itemnumber: BA11665S2A

flanged ball valve with pneumatic actuator; ATEX II 2 G/D c T3; flange PN63; body steel; ball AISI 304; ball seal fibre-glass-reinforced PTFE; stem seal graphite/PTFE/FKM; single acting actuator ATEX II 2 G/D c T6; control pressure 4...8bar; medium temperature -20...+160°C; pressure range 0...40bar; nominal diameter 65mm; length 125mm; actuator PAS1604

2.690,10 € 2690.1 EUR 2.690,10 €

Design
- ATEX

This combination does not exist.

Availability:

Add to cart

Specifications
Spare Parts

Design

ATEX

BA116-65-L-A x 1.0

Flanged ball valve BA116-65-L-A

Flanged ball valve Series BA116-L-A; ATEX II 2 G/D; Flange PN63, Full bore; Body steel A350-LF2, Ball 1.4301; Seals Fibre-glass-reinforced PTFE/PTFE/Graphoil/FKM; Pressure range 0…63bar; Medium temperature -20...+160°C; Nominal diameter 65mm; Length 125mm

Add to Cart

PAS1604 x 1.0

Pneumatic actuator PAS1604

Pneumatic actuator Series PAS; ATEX II 2 G/D; Single acting; Rotation angle 90°; According to ISO 5211/NAMUR; Operating pressure range Max. 8bar; Diameter 160mm; Flange ISO5211 F10/F12; Female square 27mm; Torque at 5,5bar 185Nm

Add to Cart

RI3010 x 1.0
