BA891-10-L-A3C
Ball valve made of stainless steel Series BA891-L-A3C; ATEX II 2 G/D; Fire-safe; TA-Luft; Full bore; Two-parts type; Female thread; Body, Ball 1.4401; Seals PTFE-Graphite reinforced/FKM; Medium temperature -20...+160°C; RP 1"; Nominal diameter 15mm; Pressure range 0...105bar; Length 93mm; Incl. Inspection certificate EN-10204-3.1; For material, pressure, function and tightness
Country of origin: Italy
Short Itemnumber: BA89110LA3C
Ball valve made of stainless steel Series BA891-L-A3C; ATEX II 2 G/D; Fire-safe; TA-Luft; Full bore; Two-parts type; Female thread; Body, Ball AISI 316; Seals PTFE-Graphite reinforced/FKM; Medium temperature -20...+160°C; RP 1/2"; Nominal diameter 15mm; Pressure range 0...140bar; Length 66mm; Incl. Inspection certificate EN-10204-3.1; For material, pressure, function and tightness
| dimension | |
|---|---|
| Female thread | RP 1" |
| DN | 25 mm |
| Length | 93 mm |
| design | |
| Design | ATEX |
| pressure | |
| Pressure range | 0...105 bar |
