GFÖ025

Name: GFÖ025
Brand: STASTO
SKU: GFÖ025
Price: 285.7 EUR
Availability: InStock

STASTO Combination
fully assembled and tested
NWT63-100
profile magnetic cylinder series NWT; according to ISO 15552, VDMA; double acting; pressure range 0,5...10bar; adjustable cushions; diameter 63mm; stroke 100mm; piston rod thread M16x1,5; connection 3/8"; push force at 6 bar 1869N
XFL/63
flange bracket series XFL; for cylinder ISO 15552; diameter 63mm
G-50-63
rod clevis series G; for cylinder; thread M16x1,5; diameter series NWT, RWS, ACMT-ISO 50, 63mm; diameter series NSKU-M 80mm
U-50-63
lock nut series U; for piston rod; for cylinder; thread M16x1,5; diameter series NWT, RWS, ACMT-ISO 50, 63mm; diameter series NSKU-M 80mm

Intrastat No.: 84123100
Country of origin: Italy
Weight: 3.029 Kg
Short Itemnumber: GF025

285,70 € 285.7 EUR 285,70 €

Connection
- -
Dimension
- -
Function
- -
Max. inlet pressure
- -
Flow at 6bar/Δp=1bar
- -
Filter element
- -

This combination does not exist.

Availability:

Add to cart

Specifications
Spare Parts

No Specifications

PC60-63-100 x 1.0

Profile magnetic cylinder PC60-63-100

profile magnetic cylinder series PC60; according to ISO 15552, VDMA; double acting; pressure range 0,5...10bar; adjustable cushions; diameter 63mm; stroke 100mm; piston rod thread M16x1,5; connection 3/8"; push force at 6 bar 1869N
