MSP003

Name: MSP003
Brand: STASTO
SKU: MSP003

STASTO Combination; Air station 2,5bar

Intrastat No.: 84814090
Country of origin: Germany
Weight: 0.62 Kg
Short Itemnumber:MSP003

STASTO Combination; air station 2,5bar

cena na zahtevo

This combination does not exist.

Availability:

Specifications
Spare Parts

No Specifications

C0C72-M14-B x 1.0

Coupling DN 7,2 C0C72-M14-B

Coupling DN 7,2; Male thread; Brass; Seal NBR; Pressure -0,87...35bar; Temperature Max. 100°C; Thread 1/4"

Add to Cart

1801-1/4" x 1.0

Ball valve made of brass 1801-1/4"

Ball valve made of brass Series 1801; Full bore; Female/male thread; Seal PTFE; Medium temperature -20...+160°C; Hand lever Aluminum; Connection RP/R 1/4"; Nominal diameter 8mm; Pressure range 0-64bar; Length 59mm

Add to Cart

SV01-14-7.5-2,5 x 1.0

Safety valve FKM-1/4"-7,5-2,5

Safety valve Series SV01; With twist lifting; Body Brass; Compression spring Stainless steel; Application: Compressed air, Non-toxic and non-inflammable gases, which are allowed to flow freely; Medium temperature -60…225°C; Seal FKM; Connection G 1/4"; DN 7,5mm; Set pressure 2,5bar

Add to Cart

TH38C-14-B x 1.0

Hex nipple TH38C-14-B

Hex nipple Series TH38C; Brass; Conical thread; Thread 1/4"

Add to Cart

16.0962 x 1.0

16.0962

T-distributor; Material Brass; Female thread; Thread 1/4"

Add to Cart

MA001-63R-4-D x 1.0

Bourdon tube manometer MA001-63R-4-D

Bourdon tube manometer Series MA001; Body Sheet steel; Measuring unit, Motion work Copper based alloy; Front glass Acryl; Ambient temperature -20...+60°C; Medium temperature Max. +60°C; Connection Rear; Class 1,6; Diameter 63mm; Indicating range 0-4/0-58; Unit bar/psi; Connection 1/4"

Add to Cart
