PIN002

PIN002

STASTO Combination
Valve unit 4-fold
Fully assembled and tested
Consists of:
4 x 5/2-way valve G1/4", 230V
Outlets Hose 8mm
Inlet Hose 8mm

Intrastat No.: 84812090
Country of origin: Italy
Weight: 2.012 Kg
Short Itemnumber: PIN002
https://www.stasto.si/web/image/product.template/221535/image_1920?unique=ba7a68c

STASTO Combination
valve unit 4-fold
fully assembled and tested
consists of:
4 x 5/2-way valve G1/4", 230V
outlets hose 8mm
inlet hose 8mm

726,30 € 726.3 EUR 726,30 €

cena na zahtevo

excl. tax
  • Connection
  • Dimension
  • Function
  • Max. inlet pressure
  • Flow at 6bar/Δp=1bar
  • Filter element
  • Brand

This combination does not exist.

Availability:
See availability
Contact Us

Technical specifications

Brand STASTO
Brand STASTO
Manifold sub-base ME414
ME414 x 1.0 Pcs
Manifold sub-base ME414
Manifold sub-base Series ME; For way-valves Series E5 And V5; Anodized aluminum; Number of valves 4; Pressure connection 3/8"; Exhaust ports 3/8"; Valve size 1/4"
5/2-way valve E52W1SM14
E52W1SM14 x 4.0 Pcs
5/2-way valve E52W1SM14
5/2-way valve Series E5.; Pilot-operated; Actuation Electrical/spring; Standard coil C001; Connector size 22mm; Connection 1/4"; Nominal diameter 8mm; Pressure range 2,5-10bar; Flow rate 1080Nl/min
C001-22
C001-22 x 4.0 Pcs
C001-22
Coil Type C001; Connector size 22mm; Voltage 230V/50-60Hz
C002-31-LV-1
C002-31-LV-1 x 4.0 Pcs
C002-31-LV-1
Connector; Connector size 22mm; With integrated LED-yellow and VDR; Voltage 230VAC/DC
Plug screw TH50-38-N-0
TH50-38-N-0 x 3.0 Pcs
Plug screw TH50-38-N-0
Plug screw Series TH50; Nickel plated brass; With o-ring NBR; Cylindrical thread; Hexagon socket; Thread 3/8"
Silencer SLN-M38-RB
SLN-M38-RB x 2.0 Pcs
Silencer SLN-M38-RB
Silencer Series SLN-RB; Sinterbronze; Thread Steel copper plated; Operating pressure Max. 16bar; Connection 3/8"; Length 36mm
