RTA004

RTA004

STASTO Combination
fully assembled and tested
consists of
1x filter regulator series FR01/FR
relieving; drain valve semi-automatic
pressure range 0,5...8bar; filter element 20µm
plastic bowl with protection cage; connection 1/2"
max. inlet pressure 12,5bar
1x manual shut-off valve series MBA
3/2-way; lockable; connection 1/2"
max. inlet pressure 12,5bar; exhaust port 1/4"
2x coupling DN 7,4; safety coupling
male thread; 360° turnable
anodized aluminum/nickel plated brass
pressure 0...12bar; thread 1/2"

Intrastat No.: 84811005
Country of origin: Italy
Weight: 1.631 Kg
Short Itemnumber: RTA004
https://www.stasto.si/web/image/product.template/218756/image_1920?unique=351c77c

STASTO Combination
fully assembled and tested
consists of
1x filter regulator series FR01/FR
relieving; drain valve semi-automatic
pressure range 0,5...8bar; filter element 20µm
plastic bowl with protection cage; connection 1/2"
max. inlet pressure 12,5bar
1x manual shut-off valve series MBA
3/2-way; lockable; connection 1/2"
max. inlet pressure 12,5bar; exhaust port 1/4"
2x coupling DN 7,4; safety coupling
male thread; 360° turnable
anodized aluminum/nickel plated brass
pressure 0...12bar; thread 1/2"

301,20 € 301.2 EUR 301,20 €

cena na zahtevo

  • Connection
  • Dimension
  • Function
  • Max. inlet pressure
  • Flow at 6bar/Δp=1bar
  • Filter element

This combination does not exist.

Availability:
Contact Us

Share

No Specifications
Filter regulator FR-12-20-08-R-PE-SS
FR-12-20-08-R-PE-SS x 1.0
Filter regulator FR-12-20-08-R-PE-SS
Filter regulator Series FR01/FR; Relieving; Drain valve Semi-automatic; Pressure range 0,5...8bar; Filter element 20µm; Plastic bowl with protection cage; Connection 1/2"; Flow at 6,3bar/Δp=1bar 2880Nl/min; Max. inlet pressure 12,5bar
Add to Cart
K-BRL
K-BRL x 1.0
K-BRL
Mounting bracket; Suitable to series FRL3-38/34, FRL-38/34, FR-38/34, R-38/34
Add to Cart
Coupling DN 7,4 C0C74-M12-T-SS-360
C0C74-M12-T-SS-360 x 2.0
Coupling DN 7,4 C0C74-M12-T-SS-360
Coupling DN 7,4; Safety coupling; Male thread; 360° Turnable; Anodized aluminum/Nickel plated brass; Seal NBR; Pressure 0...12bar; Temperature Max. 70°C; Thread 1/2"
Add to Cart
